一、Specification
1、Width：≤600mm
2、Thickness of the sheets：0.3~1mm
3、Speed：200pcs/min
4、Max.transverse stroke：≤20mm
5、Max.vertical stroke：≤10mm
6、Eccentricity of shaft：12mm
7、Motor power：2.2kw
8、Power supply：380V/50Hz
9、M/C weight：700kg
10、M/C size：1090×710×1450mm(L×W×H)
二、 Features
1、The machine is equipped with single materials feeding system, which feeded correctly and easy to adjust the length.
2、Auto-cut according to set length.
3、Different rhombus net produced by changing blades.
4、High speed drawing machine with high efficiency, steady property and easy operation.
三、Applications
This machine is used for making the inner and outer mesh of the air filter.
