一、Consists
1、Auto de-coiler
2、Pre-slitter system
3、Auto counter
4、Six pairs rollers in cycle
5、Pleating and collecting system
6、Heater for forming paper
7、Conveyer device
二、Specification
1、Speed：0~30m/min
2、Max.width：600mm
3、Min.width：30mm
4、Max.height：50mm
5、Min.height：10mm
6、Customize the rollers size
7、Heating power：6kw
8、Temperature control：normal~300℃
9、Overall power of the production line：7.5kw
10、Working air pressure：0.6MPa
11、Power supply：380V/50HZ
12、M/C weight：1100kg
13、M/C size：6600×1230×1100mm(L×W×H)
三、Features
1、The pre-slitter uses pneumatic slitting blades, it is simple regulated and evenly pressed.
2、 Six sets of rolls are equipped in the same round table which can be easily changed and suitable for producing in different specifications.
3、The machine can also make convex hull on paper which is especially suitable for the heavy duty air filter.
4、The process of the machine is auto counting, pleating, pre-heating, forming.
5、This machine has stainless steel conveyer device, so the filter paper is pleated much more evenly and smoothly.
6、It is easy to operate through the computer control.
四、Applications
This machine is specially designed and manufactured to pleat fuel、oil and heavy duty air filter elements.
