一、Specification
1、Rated capacity：100KVA
2、Rated primary voltage：380V/50Hz
3、Phase number：1
4、Adjustable series：2
5、Rated primary current：263A
6、Working air pressure：0.4MPa
7、M/C weight：700kg
8、M/C size：1070×520×1950mm(L×W×H)
二、Features
1、Through pneumatic motive,the electrode impacts the unit to be welded ,and the welding current directly heat up the machine to achieve the spot-welding action.The welding time is fast and efficient,but quality is high and reliable.
2、The upper and lower working strokes of the upper motor can be regulated evenly,as well as the assistance stroke.
3、The welding machine controller has following procedures to be automatically controlled：pressurization,power on,retaining,stop etc.
4、Equipped with cooling system.
三、Applications
It is technically used to weld the screw bottom plate and fixed plate of the auto oil and fuel filters.
