一、Specification
1、Prodcutction capability：12 cans/min
2、Sealing diameter：Φ50~Φ120mm
3、Sealing parts assembly height：50~300mm
4、The thickness of the plate：0.5~0.8mm
5、Motor power：2.2kw
6、Working air pressue：0.6MPa
7、Power supply：380V/50Hz
8、M/C Weight：600kg
9、M/C size：860×640×1750mm (L×W×H)
二、Features
1、 Electric and pneumatic controls are used by the seaming machine. The feed movements is carried out for the first roller and second roller by tow sets of cam mechanics.
2、Loading and unloading of the processing port will be done by the pneumatic parts that is controlled by the pre-determined program.
3、Adopts manual mode by pressing the button in favor of the operators' security.
4、The sealing wheel uses cr12mov of high as-quenched hardness and fine wear resistance to lengthen the service life.
三、Applications
The machine is professional used to seal the shells of rotary type and fuel filter with sealing back plate.
