一、Specification
1. Product capacity: 35-45 cans/min
2. Seaming diameter: Φ56- Φ110mm
3. filter assemble height： 50-270mm
4. steel thickness range： 0.5-0.8mm
5. turntable deciles： 12
6.motor power： 5 KW
7.working air pressure： 0.6Mpa
8.power supply ：  380V/ 50HZ
9. weight： 600kg
10 .M/C size： 700mm×985mm×2060mm( L*W*H)
               5050mm×340mm×1415mm( L*W*H)
               2050mm×250mm×925mm( L*W*H)
               500mm×320mm×1085mm( L*W*H)
11.conveyer belt length： left 3000mm right 2000mm
二. Features
1.Electric and pneumatic controls are used by the seaming machine. The feed movements are carried out for the first roller and second roller by two sets of cam mechanics.
2.Loading and unloading of the processing port will be done by the pneumatic parts that are controlled by the pre-determined program.
3.The sealing wheel uses cr12mov of high as- quenched hardness and fine wear resistance to lengthen the service life.
4.This machine adopts the high precise import divider to ensure the seaming quality.
5.This is high speed seaming machine, has the completely automatically circulation of the up-loading, seaming and down-loading.
三 Applications
This machine is mainly used for seaming the shells of the spin-on oil& fuel filters.
