一、Specification
1、Production capability：80~180 pcs/h
2、Adjustable coil diameter：Φ50~Φ130mm
3、Adjustable coil width：70~120mm
4、The capacity of holt melt unit：10kg
5、Heating power of hot melt unit：6kw
6、Power supply：220V/50Hz
7、Working air pressure：0.6MPa
8、M/C weight：700kg
9、M/C size：2463×1219×2033mm(L×W×H)
二、Features
1、Can freely adjust the rolling speed to appropriate tightness according to the size of coil diameter.
2、Through managing the three-stage counter and approach switch to obtain diversified coil diameter.
3、 Melted quickly,the glue delivered quantity can be easily controlled by frequency converter,and the hose and nozzle control the temperature independently.
4、Throgh PLC program,injection cylinder controls the glue injected in the middle of,and left or right of the paper tube,so as to ensure no leakage in paper core.
5、Have the function of time heat the hot melt unit automatically,and so time is saved.
6、This machine can corrugate double layers of fuel filter paper.
7、All the electric elements use advanced products from abroad and have a long working time.
三、Applications
It is technically suitable for shaping the CAV coil paper of filter element.
