一、Specification
1、Production capability：12cans/min
2、Sealing diameter：Φ50~Φ130mm
3、Sealing parts assembly height：50~325mm
4、Sealing parts steel plate max.thichness：1mm
5、Delivery range：150mm
6、Motor power：4kw
7、Working air pressure：0.6MPa
8、Power supply：380v
9、M/C weight：800kg
10、M/C size：940×640×2150mm(L×W×H)
二、 Features
1、 The machine uses safe physical construction and well-suited electric control,adopting pneumatic operation,working fast and sensivive.
2、Of high automatic degree：delivery~clutch~sealing wheel onward or backward~seal are automatically performed in order,so it is efficient and quality safeguarded.
3、With cycle control function,convenient and safe.
4、Adopts manual mode by pressing the button in favor of the operators' security.
5、The sealing wheel uses cr12mov of high as-quenched hardness and fine wear resistance to lengthen the service life.
三、 Applications
The machine is professional used to seal the shells of rotary type and fuel filter with sealing back plate.
