一、Specification
1、Diameter of goods：≤Φ125mm
2、Printing speed：1000 pcs/h
3、Length of goods：≤320mm
4、Working air pressure：0.6MPa
5、Power supply：220V/50Hz
6、M/C weight：100kg
7、M/C size：700×900×1250(L×W×H)
二、 Features
1、 The machine employs safe physical construction and well suited electric control, adopting pneumatic operation, working fast and sensitive.
2、The machine which load and print automatically is high efficiency and good quality.
3、Accurate printing could be made as the screen plate itself is able to move and easy to operate.
三、Applications
It is specially used for printing the shell of the filter.
