一、Specification
1.Test flow:5L/ min-50L/min
2.Flow precision:1grade
3.Temperature control: normal temperature-100°
4.pressure precision: 0.5grade
5.oil tank: stainless steel, capacity:50L
6.motor power: 3.7kw
7.power supply: 380V/50HZ
8.M/C weight：500kg
9.M/C size: 2000*1100*1885mm /600*575*1620mm ( L*W*H)
二. Features
1.Measure test flow through high-precise ellipse gear flow meter.
2.Use precise pressure gauge to measure the pressure when oil in and out.
3.The working table uses stainless steel, and the pipelines and couplers use rust preventing material.
4.To test filter’s blocking life, impurity substance is mixed evenly with impurity affix system.
5.Test criterions: JB/T6725-93， ISO4548
三. Applications
It is used to test: differential pressure/flow properties, bypass element property, by valve response pressure, filter element blocking life, filter element high-pressure resistance loss, high-oil-temperature resistance.
