一、Consists
1、Fabric placing system
2、Roll loading system
3、Moving fabric cutting system
4、Convey working table
5、Electrical control cabinet
二、Specification
1、Production capability：20~30m/min
2、Cutting width：≤850mm
3、Cutting length：300~980mm
4、Working air pressure：0.6MPa
5、Power supply：220V/50Hz
6、Motor power：0.8kw
7、M/C weight：300kg
8、M/C size：2100×1300×1100mm(L×W×H)
三、Features
1、This machine is equipped with automatic electrical control system which can easily regulate the length of cutting easily.
2、The machine is high efficiency and dimple to operate.
3、 This machine can automatically record the production capability. When it is operated incorrectly, rapidly press the emergency button, then no products will be wasted.
4、The tangent plane can be kept neat and straight while cutting, so it is easy to sew up the interface.
四、Applications
It is used for cutting the fabric-bag filter.
