一、Specification
1、Production capability：3m/min
2、Product height：20~300mm(adjustable)
3、Product width：≤700mm
4、Coil diameter：≤Φ600mm
5、Power supply：220V/50Hz
6、Working air pressure：0.6MPa
7、M/C weight：500kg
8、M/C size：2030×1120×1620mm(L×W×H)
二、 Features
1、Automatically pleat the composited materials, especially suitable for max,height products pleating.
2、The pleating height regulated by computer with high precise control.
3、Easy operation with pneumatic materials de-coiler.
三、 Applications
This machine is specialized in pleating the composited materials of primary-medium efficiency filters.
